DYNOMAN PERFORMANCE - Austin, Texas

DP COMETIC
CYLINDER BASE GASKETS
FOR CB750 SOHC
Made in the USA

SLEEVE SIZES:
750 to 836cc | 890-915cc | 970-1000cc | 1080cc

GASKET MATERIALS:

FIBER	RUBBER COATED STEEL (RCS)	COPPER
Quality hi-temp fiber gasket for street or racing use. Dynoman is slowing phasing these gaskets out of our stocking inventory in favor of the RCS gaskets, but they will be available by special order.	Rubber coated single layer steel base gaskets are Viton® rubber coated with a steel core and in some instances embossed	Highest quality copper, especially for racing use; reusable if annealed.

750 TO 836cc 2.79" / 70.5mm ID
GASKET MATERIAL	THICKNESS	PART #	ORDER
Fiber
Available by special order Approx 10 days	.010"	DP B-750-F010
	.015"	DP B-750-F015 (C8289)
	.020"	DP B-750-F020
Rubber Coated Steel Viton®
	.010"	DP B-750-RC010
	.020"	DP B-750-RC020
Copper
	.005"	DP B-750-COP005 (C8286)
	.010"	DP B-750-COP010 (C8287)
	.016"	BP-B-750-COP016
	.020"	DP B-750-COP020 (C8288)

890-915cc 2.90" / 73.7mm ID
GASKET MATERIAL	THICKNESS	PART #	ORDER
Fiber
Available by special order Approx 10 days	.010"	DP B-900-F010
Available by special order Approx 10 days	.020"	DP B-900-F020
Rubber Coated Steel Viton®
	.010"	DP B-900-RC010
	.020"	DP B-900-RC020
Copper
	.005"	DP B-900-COP005
	.010"	DP B-900-COP010
	.020"	DP B-900-COP020

970-1000cc 3.075" / 78.11 mm ID
GASKET MATERIAL	THICKNESS	PART #	ORDER
Fiber
Available by special order Approx 10 days	.010"	DP B-1000-F010
Available by special order Approx 10 days	.020"	DP B-1000-F020
Rubber Coated Steel Viton®
	.010"	DP B-1000-RC010
	.020"	DP B-1000-RC020
Copper
	.005	DP B-1000-COP005
	.010	DP B-1000-COP010
	.020	DP B-1000-COP020


1080cc
Please contact us for ordering information on 1080cc base gaskets. Different sleeve manufacturers will have varied requirements for the gasket i.d. HEAD Gaskets
